Aluminum Plate For Shipbuilding - Haomei Aluminium
- Alloy: 5083 5086 5052 6061 5454
- Temper: H32, H111, H116, H321
- Shape: Plate, Sheet, Tread Plate
- Application: Marine Ship Building
- Certification: ISO9001, CCS, DNV
- Delivery Time: 20-30 Days
The corrosive nature of water and saltwater dictates the use of special materials for shipbuilding, off-shore drilling platforms, and more. Due to its many beneficial properties, marine grade aluminum is eminently suitable for building seafaring vessels and structures, as well as the machinery and components used within them.
As ships travel at sea, the quality of aluminum plates used in ships must be guaranteed. There are also several types and uses of marine aluminum plates, and different marine application scenarios are different. What are the types of marine aluminum alloys? The commonly used alloys for marine grade aluminum plate for shipbuilding are mainly 5000 series and 6000 alloys, 5083, 5086, 6061 aluminum plates and other alloys. Most of the alloys are H111/H112/H321, and the common thickness is 1/2/3/4/5 mm.
Haomei Aluminum supplies several grades of marine grade aluminum in a variety of stock forms, including plate, sheet, coil, pipe, tube, bars, and extrusions We can also provide them with varying degrees of temper. The grades we can provide include:
5083 marine-grade aluminum is ideal for applications that need superlative corrosion resistance in hostile environments. 5083 is the strongest non-heat treatable aluminum alloy and maintains its strength even after welding.
This alloy is highly conductive with superior corrosion resistance. 5086 can be strengthened through strain hardening and cold working until it is even stronger than in 5083. Though compatible with multiple welding methods, electric arc welding is preferred for this alloy.
The beneficial properties of 5454 include high strength, superior corrosion resistance, and good formability and weldability.
Widely used for structural applications, 5456 is well-suited to the extrusion process. It is also amenable to forming operations like rolling and forging. 5456 can be made stronger through cold working, but the process reduces its ductility.
Its superior resistance to corrosion makes 5754 very suitable for the marine industry and other industrial applications possessing corrosive operating environments. It is also suitable for flooring applications due to its high strength.
The Specification of Aluminum for Shipbuilding
Aluminum Grade Temper
Yield strength (psi)
Ultimate Tensile Strength (psi)
Marine grade. Most suited for forming operations, very good corrosion resistance. Suitable for fresh water and trailered boats.
33,000 12% elong.
5083-H321 (Interchangeable With: H111 H116)
Marine grade. The highest strength non-heat-treatable aluminum alloy in commercial use. It retains excellent tensile strength in the weld zone. Excellent corrosion resistance. Suitable for salt water or fresh.
46,000 16% elong.
Marine grade. Medium to high strength non-heat-treatable alloy. More formable than 5083. Excellent corrosion resistance. Most often used to build boat hulls (in addition to 5052 or 6061) due to stress corrosion cracking resistance. Best alloy for salt water.
42,000 12% elong.
Marine grade, often used as stiffeners to build boat hulls and other components. The most often used aluminum alloy for its strength, heat treatability, workability and weldability.
45,000 17% elong.
Softer and lower strength than 6061, good for forming, high surface finish, excellent for anodizing. Good for railings, gunnels etc. where forming is required.
Used when significant machining is required, it contains lead and bismuth to partially lubricate the cutting tool. Good strength and corrosion resistance. High surface finish possible.
Marine grade aluminum for shipbuilding is specifically developed to make it ideal for use in marine environments. As such, it possesses a number of properties required in these applications. Some of these properties include:
Superior corrosion resistance
Lightweight with a high strength-to-weight ratio
Compatibility with a variety of fabrication processes
Wide availability in sheets, extrusions, and plates
Good fatigue resistance
The Application of Marine Grade Aluminum for Shipbuilding:
1. Marine plate
2. Inner and outer siding
3. Ship Structural Part
4. Side of ship
5. External board of ship bottom
6. Operation room funnel
7. Ship deck
