5183 welding wire is equal to AWS A5.10, ER5183 welding wire is an aluminum-magnesium welding wire with a magnesium content of nearly 5% and a higher manganese content. 5183 aluminum welding wire is used for welding aluminum-magnesium substrates (such as 5083 and 5654) that require high tensile strength (such as 276MPa or higher), as well as excellent resistance to seawater corrosion and low-temperature performance. The weld seam becomes white after anodizing treatment, providing a good color match for the welded joint. ER5183 aluminum welding wire is suitable for welding aluminum alloys used in ship structures, marine platforms, low-temperature containers, railway locomotives, and the automotive industry.

Aluminum-magnesium 5183 welding wire with a magnesium content of around 4.5% has characteristics such as high strength, good resistance to seawater corrosion, and high fracture toughness. ER 5183 welding wire is suitable for welding certain 5000 series, 6000 series, and 7000 series load-bearing structural components, such as 5083, 6061, 6063, 5086, 7005, and 7039 aluminum.

Specifications for aluminum-magnesium welding wire ER5183: 0.9mm, 1.0mm, 1.2mm, 1.6mm, 2.0mm, 2.4mm, 3.0mm, 4.0mm.

Packaging for aluminum-magnesium welding wire ER5183: 2kg/spool, 6kg/spool, 7kg/spool, 9kg/spool, and 10kg/box.

Application areas for 5183 aluminum welding wire: shipbuilding, coastal facilities, low-temperature workshops, pressure vessels, rail transportation, and the automotive industry, etc.

Product certifications of Haomei Aluminum's aluminum welding wire: DB, CE, CCS, ABS, DNV, etc.

Aluminum-magnesium welding wire ER5183 can be used for welding substrates such as 5050, 5052, 5083, 5356, 5454, and 5456 aluminum grades. 5183 welding wire is widely used in industries such as chemical pressure vessels, nuclear energy, shipbuilding, refrigeration, boilers, aerospace, etc. Haomei Aluminum is a professional manufacturer of aluminum welding wire with strong production capacity and large inventory. In addition, we want tot highlight our marine grade aluminum plate, aluminum profile, aluminum tread plate used for shipbuilding. We have good products waiting for you to choose.
